JAC 40 Tons 310hp Sand Tipper Truck For Sales

JAC 6*4 Dumping truck(also called heavy duty dumper truck, JAC dump tipping truck, 10 Wheel Tipping Truck, 40tons dumper trucks, Hyva front lifting tipper truck, rear tipping dump truck, hot sale tipper lorry, low price sand tipper truck) is designed for both overseas and domestic high end heavy truck markets. In order to prevail over its rivals in the global competition, key components of the tipper truck are designed in close collaboration with top suppliers in the world.

Description FEEDBACK

JAC 6*4 40 Tons 310hp Sand Tipper Truck For Sales

JAC 6*4 Dumping truck (also called heavy duty dumper truck, JAC dump tipping truck, 10 Wheel Tipping Truck, 40tons dumper trucks, Hyva front lifting tipper truck, rear tipping dump truck, hot sale tipper lorry, low price sand tipper truck) is designed for both overseas and domestic high end heavy truck markets. In order to prevail over its rivals in the global competition, key components of the tipper truck are designed in close collaboration with top suppliers in the world.



Dump truck is manufactured using the cutting-edge technology and components in the world such as WABCO double-cylinder air compressor, brake valve, HYVA front hydraulic system, etc.



 Key Features:

---- JAC heavy duty chassis, perfect performance
---- WEICHAI diesel engine, super powerful; reliable performance, no overhaul within 100,000 km.
---- Payloading from 20ton to 100 tons.
---- Easy operation and easy maintenance.

---- Various types of tipper body are available.

JAC 6*4 tipper truck (40 tons)

General

Chassis Brand

JAC

Overall Dimension

8495 * 2500 * 3500 mm

GVW / Kerb Weight

25,000kg / 12,450kg

Cab

Cab Capacity

3 persons allowed

Air Conditioner

Heating/cooling air conditioner

Engine

Fuel Type

Diesel

Engine Brand

WEICHAI diesel engine

Power

310 HP (228 KW)

Displacement

9726 ml

Emission Standard

Euro 3 or 4

Chassis

Drive Type

6X4, (LHD or RHD)

Transmission

FAST  10 speed levers with 2 reverse

Wheelbase/No. of axle

3900+1350 mm / 3

Tire Specification

11.00R20

Tire Number

10 tires and 1 spare tire

Max Speed

85 km/h

Paint

Metallic paint

Superstructure

Pay loading capacity

40 Tons

Cargo body

5600*2300*1500

Thickness of cargo body

Option 1: Bottom 8mm, Side 6mm

Option 2: Bottom 10mm, Side 8mm

Cylinder type

T Type or Domestic 180 or HYVA 150

Lifting system

Middle or Front

Control

in the cabin

Color & LOGO

According to wish

All standard accessories: All steel body with drop sides. Auto release removable tailgate.

Ladder, warning lights, PTO

 fire extinguisher, basic tool kit, English manual……

Optional

** Back alarm and Camera can be equipped.

** Other tipper body can be choose.

** Other material and plate thickness can be choose.
