Isuzu 6X4 20000liters Carbon Steel Stainless Steel Aluminum Alloy Oil Tank Truck Fuel Transport Oil Delivery
Fuel tank truck: according to the different types of transport medium, configuration and different places called, there are many different titles, such as tank car, tank truck, oil truck, oil supply car, oil puller, flow refueling car, tax control refueling car, computer tanker, diesel transporter, gasoline transporter, coal tar carrier, Lubricating oil transporters, edible oil transport vehicles, crude oil transporters, heavy oil transporters, oil tanker and so on.
Description FEEDBACK

Isuzu 6X4 20000liters Carbon Steel Stainless Steel Aluminum Alloy Oil Tank Truck Fuel Transport Oil Delivery

Fuel tank truck: according to the different types of transport medium, configuration and different places called, there are many different titles, such as tank car, tank truck, oil truck, oil supply car, oil puller, flow refueling car, tax control refueling car, computer tanker, diesel transporter, gasoline transporter, coal tar carrier, Lubricating oil transporters, edible oil transport vehicles, crude oil transporters, heavy oil transporters, oil tanker and so on.

All the tank trucks can be designed as chemical vehicles, all kinds of heating and insulation tanks; all the tank cars can be equipped with computer tankers; wide range of tonnage selection to meet the user‘s needs; the tank has multiple anti wave baffles. High pressure gas leakage test is used to make the tank body with high strength, stable center of gravity and safe and stable transportation of vehicles.

Description:

1. Tank material: we can provide carbon steel tanks, stainless steel tanks, manganese steel tanks, aluminum tanks, steel with plastic (or rubber) tanks and plastic tanks.
2. Good welding: tank body is adopted an advanced automatic vertical welding techniques and head arc butt welding technology, as well as the whole- steel forming a composite.
3. High safety: equip with active and passive emergency protection devices, to provide full closure remote manipulation of materials handing functions. Equip separators [Baffle] to prevent surging of liquid towards bulk head
4. Function: The tank body is suit for loading light fuel oil, heavy oil, sulfuric acid, hydrochloric acid, nitric acid, caustic soda hydrogen peroxide, alcohol, benzene, cooking oil and so on.
5. Oil punp: gear pump, self-absorption (centrifuge) pump, chemical pump, heavy, oil pump, stainless steel pump are optional.
6. Tank shape: shape of tank body can be designed to square round, round,Heat insulation device such as heating pipes, insulation.
7. Refueling machine: the refueling machine we use are tax controled oiling machine with accurate figure of volume, sum of money,etc.
8. Optional: reading meter for outlet and inlet,self-discharge valve at rail or side of tank body, compartment quantity according to the demand.


General Technical Parameters

Overall Dimension

9900*2500*3300(mm)

Gross Vehicle Weight

25000(kg)

Curb Weight

10850(kg)

Loading Weight

14950(kg)

Chassis Specification

Chassis Parameters

Chassis Brand

ISUZU

Cabin

Row and half, Left Hand Driving

Engine

Power

260HP

Emission standard

EURO III

Displacement

7.79L

Fuel type

Diesel

Gearbox

FAST 9 Forward & 1 Reverse Gear

Front and Rear Axle load

7T/18T

Wheel Base

4350+1300(mm)

Brake System

Pneumatic

Steering Gear

Power Assistant

Tire

1000-20, 11 Pieces

Maximum speed

80(km/h)

Tank Body

Shape

Monoblock Cylinder

Total Volume(m3)

20m3

Tanker Body Material

5mm carbon steel

Manhole Cover

500mm ,1 set with 1 breather valve

Bottom Valve

1 set

Discharging Valve

1 set 80mm discharging valve

Painting

Complete Chassis sand blasting to clean rust, 1 coat of anti-corrosive prime, 2 coats of final paint

Accessories

One standard tool box
