Popular Sinotruck HOWO 6wheels 5tons Refrigerated Cold Room Van Trucks Price With Aluminum Shutter Door
1. Refrigerator truck also called frozen truck, cold truck, cooling truck.
2. It is a closed van used to transport the goods that are frozen or preserved. The refrigerator car is a refrigerated vehicle with a refrigerating unit and a polyurethane insulated compartment.
3.The truck chassis can be any brand of China. Such as Sinotruk Howo, Foton, Shacman, DONGFENG, ISUZU etc.


Description FEEDBACK

Popular Sinotruck HOWO 4X2 5tons Refrigerated Cold Room Van Trucks Price With Aluminum Shutter Door

1. Refrigerator truck also called frozen truck, cold truck, cooling truck.
2. It is a closed van used to transport the goods that are frozen or preserved. The refrigerator car is a refrigerated vehicle with a refrigerating unit and a polyurethane insulated compartment.
3.The truck chassis can be any brand of China. Such as Sinotruk Howo, Foton, Shacman, DONGFENG, ISUZU etc.


Specification

Cabin

Driving type 4x2

With three seats, With air conditioner, Left hand driven.

Vehicle Main Dimensions

Overall dimensions (L x W x H)mm

8700×2490×3850

Wheel base  (mm)

4500

Wheel track  (front/rear) (mm)

1506/1466

Approach/Departure angle(°)

19/15

Weight in KGS

Tare Weight

5000

Loading Capacity

15000

Front axles loading capacity

5000

Rear axles loading capacity

10000

Max. driving speed(km/h)

90

Engine

Brand

YUChai

Model

YC4E160-33

Type

4-stroke direct injection , 4-cylinder in-line with water cooling

Horse Power(HP)

160HP

Emission standard

Euro 2

Gearbox

Manual type, 5 Forwards & 1 Reverse

Steering Gear

Power steering

Tire

7.00-16 with one spare tire , 7 pieces

Brake System

Service brake: dual circuit compressed air brake

Parking brake:(emergency brake): spring energy, compressed air operating on rear wheels

Auxiliary brake: engine exhaust valve brake

Refrigerator Van

Refrigerator Van body



Dimensions(mm)

6100*1910*1900 mm

Van material

Glass fiber reinforced plastic

Insulating layer material

Polyurethane foam

Insulating layer thickness(mm)

80 mm

Self Contained Cooling Unit

Brand

American brand Carrier

Model

VIENT0350

Refrigerated Temperature(°)

-18ºC-0ºC
