Dongfeng 5CBM Sweeper Truck For Sales
  • Dongfeng 5CBM Sweeper Truck For Sales
  • Dongfeng 5CBM Sweeper Truck For Sales
  • Dongfeng 5CBM Sweeper Truck For Sales
  • Dongfeng 5CBM Sweeper Truck For Sales
  • Dongfeng 5CBM Sweeper Truck For Sales
Dongfeng 5CBM Sweeper Truck For Sales

Road sweeper truck is a new type of high efficient cleaning equipment which integrates road cleaning, garbage collection and transportation. it is widely used in city streets, road, station, square etc. Road sweeper truck are mainly composed of chassis, box (garbage box and water tank), sweep system, auxiliary engine, fan system, cleaning system, suction system, dust system, hydraulic system and electrical control system.

Description Get quotation

4X2 Dongfeng 5CBM Sweeper Truck For Sales


Road sweeper truck is a new type of high efficient cleaning equipment which integrates road cleaning, garbage collection and transportation. it is widely used in city streets, road, station, square etc. Road sweeper truck are mainly composed of chassis, box (garbage box and water tank), sweep system, auxiliary engine, fan system, cleaning system, suction system, dust system, hydraulic system and electrical control system. The garbage boxes and water tank produced by our company are made of stainless steel,the inside of the garbage box has filter nets, which can effectively prevent the leaves,plastic bags or other light objects to clog the tuyere. Water tank inside is anticorrosion, antirust and antitoxic. Road sweeper truck is equipped with 4 brushes, both sides of the brushes can be working together, or unilateral work independently. The operating system of road sweeping truck, rear dust absorption plate absorb the rubbish on the ground. The height can be adjust according to requirement.Road sweeper truck have an auxiliary engine which can offer power for fan and hydraulic oil pump. Fan supply suction power for the suction system, hydraulic oil pump complete the lift of van box and switching of rear door. The nozzle is installed at cleaning brushes and the rear and front of the truck to drop dust by spraying water. The control box is in the cab, all kinds of system electrical centralized to control, and easy to operate.



1. Imported high quality hydraulic motor.

2.Stainless steel garbage box with anticorrosion.

3.The cleaning brushes can avoid automatically and adjust the speed.

4. Both sides of the brushes can be working together, or unilateral work independently.


Technical Date:

Item Parameter
Production name Dongfeng 4x2road cleaning truck
vehicle model CLW5071TSL4
Engine Engine model: CY4102-CE4F
Chaoyang Diesel
Exhaust: 3856 ml
Power: 73 kw
Chassis model DFA1070SJ35D6
Tire Tire specification: 7.00-16
Number of tire: 6
Axle Number of axles: 2
Axle-load: 2920/4380
Wheel base(mm):3300
Traction system 4*2
TankVolume(cbm) 4m3 dustbin,1.0m3 clean water tank
GVW(kg) 7300
Curb weight(kg) 4800
Overall dimensions(mm) 5950×1995×2380
F / R track base(mm) 1506/1466
F/R overhang(mm) 1032/1618
Approach/departure angle(°) 19/12
Max speed(Km/h) 95
Equipments 1> Equipped with 4 sweeping brush, JMC 88 hp deputy engine; Italian motor; French control switch; Joint venture solenoid valve group; Maintenance-free self-separate clutch; Maintenance-free fan; Stainless steel water tank and dustbin; Rear LED arrow lights, manual pump for emergency system.
2> Maximum sweeping width 3.2 m, inhaled sizeφ120 mm
3> Optional: monitoring, sprinkler function, self-cleaning function for dustbin.
