Dongfeng Road Cleaning Truck For Sales

Road cleaning truck is an efficient environmental sanitation truck equipped with functions of sweeping road and high pressure cleaning road. It is widely used in city streets, road, station, square etc. Road cleaning truck are mainly composed of chassis, box (garbage box and water tank), sweep system, auxiliary engine, fan system, cleaning system, suction system, dust system, hydraulic system and electrical control system. The garbage box and water tank are made of super thick stainless steel plate. In order to prevent the early damage of the water tank and the garbage box because of corrosion, all the parts of the tank and the garbage box are made of super thick stainless steel, which greatly prolongs the service life of the whole truck.

Description FEEDBACK

Dongfeng 4x2 Road Cleaning Truck For Sales



Road cleaning truck is an efficient environmental sanitation truck equipped with functions of sweeping road and high pressure cleaning road. It is widely used in city streets, road, station, square etc. Road cleaning truck are mainly composed of chassis, box (garbage box and water tank), sweep system, auxiliary engine, fan system, cleaning system, suction system, dust system, hydraulic system and electrical control system. The garbage box and water tank are made of super thick stainless steel plate. In order to prevent the early damage of the water tank and the garbage box because of corrosion, all the parts of the tank and the garbage box are made of super thick stainless steel, which greatly prolongs the service life of the whole truck.



A large area filter net is set at the top of the box to to reduce the clogging and to ensure the fluency of suction, the top of the box is set with a flow guide slot, which improves the dust effect, makes the garbage accumulation even and improves the effective capacity. Road sweeper truck is equipped with 2 brushes, the cleaning device has the function of automatic barrier protection or automatic reset. Road cleaning truck uses a unique hand pressure pump emergency lifting system: when the auxiliary engine fails and can not start the auxiliary engine, the garbage box is raised to facilitate the maintenance of the worker. The hydraulic valve group adopts the famous leading brands: the test pressure can reach 35MPa and the flow rate is 300L/Min. The dynamic, static and fatigue life of various industrial hydraulic valves and walking mechanical hydraulic valves can be accurately tested.





1.Equipped with two-way operation button and rinse function.

2.Stainless steel garbage box with anticorrosion.

3.Cleaning device with automatic obstacle avoidance, protection or automatic reset function.

4.The angle of garbage box is high: it is easy to dump the garbage.

Item

Parameter

Production name

Dongfeng 4x2road cleaning truck

vehicle model

CLW5071TSL4

Engine

Engine model: CY4102-CE4F

Chaoyang Diesel

Exhaust: 3856 ml

Power: 73 kw

Chassis model

DFA1070SJ35D6

Tire

Tire specification: 7.00-16

Number of tire: 6

Axle

Number of axles: 2

Axle-load: 2920/4380

Wheel base(mm):3300

Traction system

4*2

TankVolume(cbm)

4m3 dustbin,1.0m3 clean water tank

GVW(kg)

7300

Curb weight(kg)

4800

Overall dimensions(mm)

5950×1995×2380

F / R track base(mm)

1506/1466

F/R overhang(mm)

1032/1618

Approach/departure angle(°)

19/12

Max speed(Km/h)

95

Equipments

1> Equipped with 4 sweeping brush, JMC 88 hp deputy engine; Italian motor; French control switch; Joint venture solenoid valve group; Maintenance-free self-separate clutch; Maintenance-free fan; Stainless steel water tank and dustbin; Rear LED arrow lights, manual pump for emergency system.
2> Maximum sweeping width 3.2 m, inhaled sizeφ120 mm
3> Optional: monitoring, sprinkler function, self-cleaning function for dustbin.
