Vehicle technical parameters

Tanker capacity

5.5m3

suction pump

Vacuum pump

Pumping full time

 <5min

emptying time

<4min

Vertical suction

≥8 m

inlet&outlet

50mm

G.V.W

4495kg

Rated Weight

1495kg

Curb Weight

2805kg

Rated passengers

3passengers

Tanker dimension(mm)

3300xΦ900

Overall dimension(mm)

5830x1980x2200

Chassis technical parameters

Chassis Brand

KAMA

Wheelbase (mm)

3300

Chassis Model

KMC1041A28D5

Tire Specification

6.50-16

axle nos

2

Tire Nos

6 tyres and 1 spare tyre

Gearbox

5-speed front, 1 reverse

Front/Rear axle

1.8/3.5ton

Fuel Type

Diesel

Brake

Oil Brake

Emission standard

Euro 5

Engine Model

Engine Brand

Displacement(ml)

Horsepower

YN33CRE1

Yunnei Power

3298

115

Basic configuration of Superstructure

Standard configuration

The special part of the sewage suction truck consists of pressure tank (using a national standard 6mm thick carbon steel plate, stainless steel tanks and plastic-lined tanks can be selected), vacuum suction pump, power take-off, drive shaft, water and gas separator, oil and gas separator,
Multi-way directional valve, Sewage discharge valve, pollution window, vacuum pressure gauge, pipe network system, hydraulic system, hand washing device. It is equipped with high-power vacuum suction pump and high-quality hydraulic system along with the vehicle. The tank can be opened hydraulically and double-top hydraulic self-unloading. The dirt in the tanker can be dumped directly through the back cover. It has the characteristics of high vacuum, large tonnage, high efficiency, and widely used.

Optional configuration

     Optional hand washing device, liquid level tube, rear window; vehicle Coating color, hydraulic self-alar, sewage suction with sprinkler and high-pressure cleaning function can be selected
