Foton 8000 Liters Suction Vacuum Sewer VAC 6 Wheel Trucks For Sales
1.there has sufficient vacuum degree of vacuum tank;
2: Secondary protection on vacuum pump settled to avoid pump got pollution
3. Vacuum pump driven by manual operation, which is easy to clutch;
4:Hydraulic pump and vacuum pump acted synchronization which is reliable;
5:Excellent appearance,easy to operation, and advanced performance.
Vacuum Trucks consist of Chassis, PTO, shaft, vacuum pump, pressure tank, hydraulic parts, pipe network system, vacuum gauge, and other components. High quality vacuum pump and hydraulic systems equipped on truck. The vacuum tank seal pressed at one time and which can open from rear tailgate and dumping. Its function has high vacuum degree, large tonnage capacity, high efficiency,ect, which can be used at wider fields, such as urban, water collection well, manholes,ect. Sewage inner tank can be shipped and exhaust discharged directly. New FOTON
Description FEEDBACK
Foton 4*2 8000 liters Vacuum/Sewer/ vac 6 wheel Trucks

1.there has sufficient vacuum degree of vacuum tank;
2: Secondary protection on vacuum pump settled to avoid pump got pollution
3. Vacuum pump driven by manual operation, which is easy to clutch;
4:Hydraulic pump and vacuum pump acted synchronization which is reliable;
5:Excellent appearance,easy to operation, and advanced performance.
Vacuum Trucks consist of Chassis, PTO, shaft, vacuum pump, pressure tank, hydraulic parts, pipe network system, vacuum gauge, and other components. High quality vacuum pump and hydraulic systems equipped on truck. The vacuum tank seal pressed at one time and which can open from rear tailgate and dumping. Its function has high vacuum degree, large tonnage capacity, high efficiency,ect, which can be used at wider fields, such as urban, water collection well, manholes,ect. Sewage inner tank can be shipped and exhaust discharged directly. New FOTON


 Engine
 Model  Phaser180Ti-30
 Rated power / horsepower  134kw/180kw
 Displacement  5,990L
 Transmission
 Model  8JS
 Brand  FAST
 Gears  8gears+1reverse
 Dimension
 Overall size (LxWxH)  7,850x2,450x3,250mm
 Wheelbase  4500mm
 Tire size / tire numbers  9.00-20/6+1spare tires
 Chassis
 Model  BJ5163
 Brand  FOTON
 Total mass / curb mass  15,800/7,005kg
 Driving type  4x2
 Max. speed  90km/h
Main Vacuum Tank Assembly Parts
Vacuum tank cubage  8,000L
Vacuum tank material  Carbon steel
 Valid suction distance  <8m
Vacuum pump model  68/7000
Vacuum pump brand  China Weilong double pumps
Vacuum pump flow  5.3m3/min

Working Video
