| Brand Name: | Foton |
| Model Number: | CLW5047XLCJ6 |
| MOQ: | 1 |
| Price: | 15000-35000 per unit |
| Payment Terms: | 50% Deposit,Balance should be paid before ship out |
| Supply Ability: | 10unit per month |
| Feature | Specification Range |
|---|---|
| Vehicle Type | Pure Electric Refrigerated Light Truck/Van |
| Gross Vehicle Weight (GVW) | 4,495 kg to 6,000 kg (Approx. 4.5 to 6 Tons) |
| Payload Capacity | Approx. 1,000 kg to 3,600 kg (Varies by model) |
| Overall Dimensions (L*W*H) | Approx. 5,995 mm * 2,100–2,260 mm * 3,080–3,300 mm |
| Refrigerated Box Dimensions (L*W*H) | Approx. 4,080 mm * 2,100 mm * 2,000–2,100 mm (Approx. 17–18 CBM) |
| Refrigeration Temperature Range | Typically −18°C to −15°C (Freezer) or −5°C to +10°C (Chiller) |
| Battery Type | Lithium Iron Phosphate (LFP), e.g., CATL |
| Battery Capacity | 81.14 kWh to 100.46 kWh (Common capacities) |
| Electric Motor (Peak Power) | 115 kW to 130 kW (Approx. 154 - 174 HP) |
| Electric Motor (Max. Torque) | 300 Nm |
| Driving Range (Full Load/Estimate) | 180 km to 400 km (Range ratings vary greatly) |
| Maximum Speed | 90 km/h to 105 km/h |
| Charging Time (DC Fast Charge) | Approx. 1.5 - 4 hours (from 20% to 100% or 80%) |
| Feature | Specification |
|---|---|
| Vehicle Model | AUMARK-C38 |
| Cabin | Single row/W1995/right rudder |
| Overall Dimensions (LxWxH) mm | 6725*2100*2280 |
| Wheel Base (mm) | 3800 |
| Curb Weight (kg) | 3305 |
| Gross Vehicle Weight (kg) | 6500 |
| Persons in Cab | 3 |
| Max. Speed (km/h) | 95 |
| Engine Model | FTTB065B |
| Engine Type | Electric |
| Battery | 100.46KWh |
| Motor | FTTB065B |
| NEDC Range | 280 |
| Gearbox Model | 6TS55 |
| Front Axle | 2.5T |
| Rear Axle | 6.0T/4.875 |
| Front Suspension/Leaf Spring Number | 9 |
| Rear Suspension/Leaf Spring Number | 11+7 |
| Service Brake | Drum pneumatic braking |
| Parking Brake | Brake gas brake |
| Auxiliary Brake | Engine exhaust brake |
| Wheels and Tyre Size | 6+1(8.25R16) |
