| Brand Name: | Foton Aumark |
| Model Number: | CLW |
| MOQ: | 1 |
| Price: | 15000-35000 per unit |
| Payment Terms: | 50% Deposit,Balance should be paid before ship out |
| Supply Ability: | 10unit per month |
Foton Aumark series, particularly when equipped with a Thermo King refrigeration unit, is a widely available and highly-specified light to medium-duty refrigerated and freezer truck used for cold chain logistics.
Model: Foton Aumark Freezer/Refrigerated Van Truck
Cooling Unit: Thermo King (USA brand, known for high reliability)
Purpose: Temperature-controlled transport for frozen/chilled goods — ideal for food, pharmaceuticals, dairy, seafood, vaccines, etc.
Temperature Range: -20°C to +20°C (customizable)
| Feature | Typical Specification/Detail |
|---|---|
| Engine | Often uses Cummins engines (e.g., ISF 2.8L or ISF 3.8L), known for their power, fuel efficiency, and reliability. Power ranges typically from 148 HP to 168 HP (or higher for larger models). |
| Transmission | Commonly paired with a reliable transmission, such as a ZF manual gearbox. |
| Brakes | Higher-end Aumark models (Aumark S) often feature a full air brake system (with discs all-around) from suppliers like WABCO, including ABS (Anti-lock Braking System) and sometimes ESP (Electronic Stability Program) for enhanced safety. |
| Tonnage/GVW | The Aumark series covers a range, with Gross Vehicle Weights (GVW) typically found between 6 tonnes to 10 tonnes for light-to-medium-duty applications. |
| Chassis Durability | Engineered with features like corrosion-resistant materials and reinforced suspension, specifically for the demanding environment of cold chain transport. |
| Construction | Built using a sandwich panel structure, typically featuring Fiber-Reinforced Plastic (FRP) or pre-painted aluminum for the inner and outer skins. |
| Insulation | High-density Polyurethane Foam (PUF) is the core insulating material. Thickness is often around 80mm to 100mm, with freezer models often using the thicker option to maintain lower temperatures. |
| Floor | A heavy-duty, anti-slip extruded aluminum flat floor is commonly used for durability and easy cleaning. |
| Box Dimensions | Internal box lengths vary widely depending on the Aumark chassis model, from around 4,100 mm up to 5,600 mm or more. |
| Doors & Hardware | Equipped with multiple doors (e.g., double rear doors and optional side doors), all featuring stainless steel door frames, hinges, and locking hardware to prevent corrosion and ensure a tight seal. |
| Unit Models | Common Thermo King models utilized include the RV380, SV400-50, T1180Pro, and RV-580. The specific model depends on the required cooling capacity and the size of the box. |
| Temperature Range | The unit is capable of achieving both refrigerated and deep-frozen temperatures. A typical range for a freezer spec is −20°C to −25°C, while a refrigerated spec is usually 0°C to +5°C. |
| Power Source | The refrigeration unit is usually a Vehicle-Powered (direct-drive) unit that runs off the truck's engine, but options for an Independent Diesel Unit or Electric Standby power (shore power) are often available for continuous cooling when the engine is off. |
| Refrigerant | Commonly uses R404A, a refrigerant suitable for freezer applications. |
Foton Aumark Refrigerator Truck Van Refrigerated Thermo King Freezer Truck Application :
| Application | Description | Temperature Range |
|---|---|---|
| 1. Frozen Foods | Ice cream, frozen desserts, processed frozen meals, frozen vegetables, and ready-to-bake dough. | Freezer Range (approx. −18°C to −25°C) |
| 2. Meat & Poultry | Frozen meat cuts, fresh refrigerated beef, chicken, pork, and prepared deli items. (Often requires meat hooks and rails inside the box.) | Freezer/Refrigerated (approx. −15°C to 0°C) |
| 3. Seafood | Fresh fish, shellfish, frozen shrimp, and other aquatic products. (The vehicle is often built with enhanced corrosion resistance, especially in the floor and trim.) | Freezer/Refrigerated (approx. −25°C to +5°C) |
| 4. Dairy Products | Milk, yogurt, cheese, butter, and eggs. | Refrigerated Range (approx. +2°C to +7°C) |
| 5. Produce | Fresh-cut flowers, fruits, and vegetables that require a cool, non-freezing environment to maintain shelf life. | Refrigerated Range (approx. +5°C to +15°C) |
Overview and Location:
Product Range: The company is known for its extensive range of trucks, with some of the leading categories including:
Established in Sep. 2004,Chengli Special Automobile Co., Ltd is an important branch of CLW group with registered capital 100,000,000 RMB(14 millions US Dollars) and total capital 6,000,000,000(840 millions US Dollars).
Chengli Special Automobile Co., Ltd. has a significant and expanding presence in the global market for special-purpose vehicles. The company actively exports its wide range of products to numerous countries and regions worldwide.
Here is a breakdown of their overseas market activity:
Key Export Regions
Chengli's products are exported to more than 80 countries and regions globally, with a strong focus on emerging markets. The main export markets include:
Trucks from Chengli Special Automobile Co., Ltd have been sold to more than 29 provinces in China and more than 80 overseas countries and regions in Asia, Africa, South America, middle east and so on, such as Russia, Mongolia, Philippines, Vietnam, Cambodia, Myanmar, Laos, Kazakhstan, Uzbekistan, Kyrghzstan, Tanzania, Zambia, Nigeria, Australia, Chile, Bolivia, Ethiopia, Sudan, Malaysia, Congo, El Salvador, Iraq, New Zealand, Chile, Bolivia, Argentina and also truck body for client drawing
Address
Chengli Automobile Industry Park,Suizhou City,Hubei Province,China
Tel
86--18995979503
