JAC 4x2 Multi Door Deep Freeze Ice Cream Transport Truck for Frozen Food Logistics

JAC 4x2 Multi Door Deep Freeze Ice Cream Transport Truck for Frozen Food Logistics

Brand Name: JAC
Model Number: CLW5042XLCB6
MOQ: 1
Price: 15000-35000 per unit
Payment Terms: 50% Deposit,Balance should be paid before ship out
Supply Ability: 10unit per month
Detail Information
Place of Origin:
China
Certification:
ISO9001, ISO14001, OHSAS18001, CCC
Product Name:
Multi-Door Refrigerated Ice Cream Transport Truck
Vehicle Chassis:
JAC Motors Light-Duty Commercial Chassis
Emission Standard:
Euro 3
Temperature Range:
-18 To -25 (Deep Freeze)
Box Body Material:
FRP (Fiberglass Reinforced Plastic) Sandwich Panels
Door Configuration:
Multi-Compartment Side Access Doors
Door Hardware:
Multi-Compartment Side Access Doors
Flooring:
Anti-Slip Checkered Aluminum Plate With Drain Holes
Export Country:
Armenia
Manufacture:
Chengli Special Automobile Co.,Ltd
Packaging Details:
Nude
Supply Ability:
10unit per month
Highlight:

JAC 4x2 ice cream transport truck

,

multi door deep freeze refrigerator truck

,

frozen food logistics transport truck

Product Description
JAC 4x2 Multi Door Deep Freeze Ice Cream Transport Truck for Frozen Food Logistics

Engineered for reliable last-mile cold chain logistics, the JAC Multi-Door Refrigerated Truck is designed for deep-freeze (-18°C to -40°C) distribution of ice cream, frozen meat, poultry, and dairy products. Built on a durable JAC light-duty chassis and equipped with a multi-compartment side-door freezer body, this vehicle maximizes operational efficiency, minimizes cold air loss during frequent stops, and ensures strict temperature integrity across ambient tropical and desert climates.

JAC 4x2 Multi Door Deep Freeze Ice Cream Transport Truck for Frozen Food Logistics Technical date:
1. Overall Vehicle Specifications
Item / Feature Technical Specification / Description
Vehicle Type Multi-Door Refrigerated Ice Cream & Frozen Food Transport Truck
Chassis Brand JAC Motors (Light-Duty Commercial Platform)
Drive Type 4x2 Left-Hand Drive (LHD)
Engine Options High-torque Turbocharged Diesel Engine (Euro 2 / Euro 3 / Euro 5 / Euro 6 compliant)
Transmission 5-Speed / 6-Speed Manual Transmission
Braking System Dual-circuit Hydraulic or Air Brake System with ABS
Tires Heavy-duty radial tubeless tires optimized for urban & highway logistics
2. Refrigerated Body & Cold Room Construction
Item / Feature Technical Specification / Description
Insulation Core High-density Polyurethane (PU) foam (45–48 kg/m³, thermal conductivity < 0.022 W/m·K)
Panel Material FRP (Fiberglass Reinforced Plastic) inner and outer sandwich structure
Side Access Doors Customized multi-compartment side doors with stainless steel hardware & double EPDM rubber seals
Flooring Anti-slip checkered aluminum plate or seamless fiberglass floor with integrated drain plugs
Internal Sub-Division Multi-compartment layout minimizing cold air exposure during frequent deliveries
3. Refrigeration System & Temperature Control
Item / Feature Technical Specification / Description
Temperature Range -18°C to -25°C (Deep Freeze for Ice Cream and Frozen Meat/Poultry)
Refrigeration Unit Top-tier international/domestic brands (Carrier, Thermo King, Hanxue, Huatai, etc.)
Drive Mechanism Direct engine-driven compressor with optional AC 220V/380V standby electric system
In-Cabin Controller Digital temperature display and control unit with fault diagnostics in cab
4. Key Advantages & Primary Applications
Category Details & Benefits
Key Advantages • Thermal Preservation: Individual compartment access prevents overall box temperature loss.
• High Payload Ratio: Lightweight FRP panel structure optimizes net carrying capacity.
• Customizable Livery: Large side panel area designed for corporate brand advertising.
Primary Applications • Ice Cream & Frozen Desserts Logistics
• Fresh & Frozen Poultry / Meat Distribution
• Cold Chain Seafood & Pre-packaged Frozen Foods
Foton Ice Cream Refrigerator Cargo Cooled Cooling Food Refrigerated Van Freezer Box Transport Truck
Optional Features
  • Dual-temperature compartments (for frozen and chilled goods together)
  • GPS and temperature monitoring system
  • Side door for easy loading/unloading
  • Electric standby unit (for overnight cooling without engine)
Foton Ice Cream Refrigerator Cargo Cooled Cooling Food Refrigerated Van Freezer Box Transport Truck Foton Ice Cream Refrigerator Cargo Cooled Cooling Food Refrigerated Van Freezer Box Transport Truck
About Chengli Special Automobile Co., Ltd

Chengli Special Automobile Co., Ltd. is a major manufacturer of specialized vehicles based in Suizhou City, Hubei Province, China. It is a core member of the larger Chengli Automobile Group (CLW Group).

Here are some key points about the company:

  • Establishment: Founded in September 2004.
  • Location: Headquartered in Suizhou City, Hubei Province, which is known as the "capital of China's special purpose vehicles."
  • Scale: It's one of the largest special automobile manufacturers in Central China, producing a vast range of special-purpose vehicles.
  • Product Range: They produce over 800 types of specialized vehicles, which can be broadly categorized into:
    • Sanitation & Municipal Vehicles: Garbage compactor trucks, water sprinkler trucks, road sweeper trucks, sewage suction trucks, dust suppression trucks.
    • Tank Trucks: Fuel tank trucks/trailers, LPG tankers/trailers, water tank trucks, chemical trucks.
    • Engineering & Construction Vehicles: Dump trucks, truck-mounted cranes (boom trucks), concrete mixer trucks, asphalt distributor trucks, aerial work platform trucks (manlifts).
    • Rescue & Emergency Vehicles: Fire trucks, ambulances, wrecker tow trucks.
    • Box & Van Vehicles: Refrigerated trucks, cargo trucks, LED advertising trucks, food trucks.
    • Others: Semi-trailers, AWD off-road trucks, and various spare parts and accessories.
  • Chassis: Their specialized vehicles are often built on chassis from major truck brands such as DONGFENG, ISUZU, FOTON, SINOTRUK (HOWO), SHACMAN, JAC, FAW, and others.

Established in Sep. 2004, Chengli Special Automobile Co., Ltd is an important branch of CLW group with registered capital 100,000,000 RMB(14 millions US Dollars) and total capital 6,000,000,000(840 millions US Dollars).

JAC 4x2 Multi Door Deep Freeze Ice Cream Transport Truck for Frozen Food Logistics
Chengli Special Automobile Co., Ltd Overseas Market

Chengli Special Automobile Co., Ltd. has a substantial and continuously expanding presence in the overseas market, exporting its wide range of specialized vehicles to numerous countries across the globe.

Their primary overseas focus appears to be concentrated on developing and emerging markets, with established sales in over 30 to 80 countries and regions (figures vary across sources).

Major Overseas Market Regions

  • Africa: This is a very strong market, including countries like Nigeria, Ghana, Angola, Tanzania, Zambia, South Africa, Senegal, Togo, Benin, Niger, Mali, and Congo.
  • Southeast Asia: A key region for exports, with destinations such as the Philippines, Vietnam, Cambodia, Myanmar, Laos, Malaysia, Singapore, and Thailand.
  • South America: Including countries like Chile, Bolivia, Peru, Panama, and Venezuela.
  • Middle East: A targeted market for their specialized vehicles.
  • Central Asia/Eastern Europe: Exports to countries like Russia, Kazakhstan, Uzbekistan, and Mongolia.
  • Oceania: Including Australia and New Zealand.

Key Exported Products
The types of vehicles they export are diverse, often reflecting the needs of the importing country for infrastructure, sanitation, and logistics:

  • Sanitation Trucks: Garbage compactor trucks, water sprinkler trucks, and sewage suction trucks are highly popular export products.
  • Tanker Trucks: Fuel tank trucks, LPG tankers, and water tankers.
  • Construction & Engineering Vehicles: Dump trucks, truck-mounted cranes, and concrete mixer trucks.
  • Emergency Vehicles: Fire trucks and ambulances.

Trucks from Chengli Special Automobile Co., Ltd have been sold to more than 29 provinces in China and more than 80 overseas countries and regions in Asia, Africa, South America, middle east and so on, such as Russia, Mongolia, Philippines, Vietnam, Cambodia, Myanmar, Laos, Kazakhstan, Uzbekistan, Kyrghzstan, Tanzania, Zambia, Nigeria, Australia, Chile, Bolivia, Ethiopia, Sudan, Malaysia, Congo, El Salvador, Iraq, New Zealand, Chile, Bolivia, Argentina and also truck body for client drawing

JAC 4x2 Multi Door Deep Freeze Ice Cream Transport Truck for Frozen Food Logistics
