Road Sweeper/Cleaning TruckYou are here:HOME >> PRODUCTS >> Road Sweeper/Cl...
hot sale dongfeng 4m3 road sweeping vehicle,road sweeper truck

1.Stainless steel garbage tank,water tank

2.Maintenance free blower with high quality,and maintenance free automatic clutch

3.Hydraulic oil pump imported from Italy, long service life, stable and reliable, low failure rate

4.Hydraulic valve imported form Germany

5.The hydraulic lines using the German standard technical seal structure, good shock resistant performance,

   high sealing reliability,can realize no leakage seal effect

6.The key electronic components using French Schneider technique

Description FEEDBACK

Hot sale dongfeng 4m3 road sweeping vehicle,road sweeper truck

1.Stainless steel garbage tank,water tank

2.Maintenance free blower with high quality,and maintenance free automatic clutch

3.Hydraulic oil pump imported from Italy, long service life, stable and reliable, low failure rate

4.Hydraulic valve imported form Germany

5.The hydraulic lines using the German standard technical seal structure, good shock resistant performance,

   high sealing reliability,can realize no leakage seal effect

6.The key electronic components using French Schneider technique



Product description

Product Name

Dongfeng 4m3 road sweeping vehicle

Product Model

dongfeng

Main parameters

Overall size(L*W*H)

5950×1995×2380mm

Gross weight

7300kgs

Rated capacity

2370,2305kgs

Curb weight

4800kgs

Approaching/Departure Angle

19/12(°)

Front/Rear suspension

1032/1618mm

Axle loading

2920/4380

Max.speed

95km/h

Chassis

Chassis Brand

Dongfeng

Chassis model

DFA1070SJ35D6

Drive type

4X2, LHD/RHD

Fuel Type

Diesel

Tire Specification

7.00-16 14PR,7.00R16 14PR

Tire No.

6

Wheelbase

3300mm

Alex No.

2

Leaf Spring No.

8/9+5,6/8+4,6/6+5

Front trend

1506,1404,1500,1441mm

Rear trend

1466,1458,1520,1500mm

Passengers in cab

2 or 3

Engine

Manufacturer

Dongfeng chaoyang diesel engine

Model

CY4102-CE4F

Horse Power

100HP

Displacement/Power

3856ml/73kw

Emission standard

Euro 4





Item

Parameters

Auxiliary engine model

JX493G

Auxiliary engine power

57kw/77.5hp

Maximum speed

≥95km/h

Cleaning width

≥2.8-3 m

Water tank volume

1.5m3

Garbage box volume

4m3

Operating speed

3~15km/h

Maximum operation ability

4500m2/h

Maximum suction size

100mm

Cleaning efficiency

≥99%




Working Video
