Road Sweeper/Cleaning TruckYou are here:HOME >> PRODUCTS >> Road Sweeper/Cl...
ISUZU 5.5cbm 75hp Diesel Small Street Sweeper Truck For Cleaning Road
road sweeper truck (also called street cleaning truck , truck mounted sweeper , Road cleaning truck , street sweeping truck ) Is used for all cleaning , brushing and vacuum collecting of surface dusts , leaves , mud , soil , sand , stone chips , gravels and other small particles on the ground of city / municipal roads and areas .
Description FEEDBACK

ISUZU 5.5cbm 75hp 4x2 Diesel Small Street Sweeper Truck For Cleaning Road


Description:

1. We can supply all brands of special trucks, such as Dongfeng, ISUZU, Sinotruck, Foton, Faw, north Benz(beiben), JAC, JMC, etc.
2. The drive type could be 4X2, 4X4, 6X4, 6X6, 8X4
3. Certification: ASM, ISO, BV, SGS, CCC etc.

Advantage:

1. The garbage bin is made of stainless steel with a filter plate inside, which can effectively prevent light objects such as leaves from blocking the air outlet and dust from being discharged.
2. Anti-corrosion, anti-rust and anti-virus treatment inside the water tank.
3. The cleaning structure of "Center 4 brush + rear suction cup", the front sweeping disk has automatic obstacle avoidance function, and the left and right sweeping brushes can be controlled separately.
4. According to the user‘s needs, it can be equipped with pre-shooting, post-sprinkling, spraying, self-cleaning reel, operation monitoring system, auxiliary suction device and snow shovel.


Technical Parameters


Condition

New condition/Left hand drive/4x2

Overall Dimension(mm)

5900x1980x2450

Gross Vehicle Weight(Kg)

6995

Loading Weight(Kg)

1900

Curb weight(kg)

4965

Chassis

Brand

ISUZU

Model

100p

Wheelbase(mm)

3360 mm

Overhang (front/rear) (mm)

1015/1815 mm

Wheel track (front/rear) (mm)

1504/1425 mm

Approach/Departure angle(°)

24/16°

Axle Load(kg)

2580/4720 kg

Max. driving speed(km/h)

110 km/h

Clutch

Reinforced diaphragm clutch

Brakes

Oil brake

Steering Gear

Power steering, hydraulic steering with power assistance

Tire

Quantity(pcs)

6pcs with one spare tire

Specifications

7.00-16 nylon tire

Gear box

Manual type, 5 Forwards & 1 Reverse

Cab

Single row seat. With air conditioner.

Engine

Model

4JB1CN

Displacement(ml)

2771 ml

Power(kw)/Horsepower(HP)

72 kw/98 HP

Cylinder quantity(pcs)

4 pcs

Diámetro x carrera(mm)

φ93×102mm

Emission standard

Euro IV

Upper

Tank

Garbage tank

Tank material

Stainless steel

Tank volume(cbm)

4.0 cbm

Water tank

Tank material

Stainless steel

Tank volume(cbm)

1.5 cbm

Auxiliary engine

Model

ISUZU

Power(kw)/Horsepower(HP)

55 kw/75 HP

Fuel type

Diesel

Sweeping System

Type

Fours brushes installed between front and rear axle,driven by gerotor motor. Left and right brushes are controlled to lift up and down separately.Rear brushes and suction nozzle are integrated controlled for up and down.

Sweeper Diameter(mm)

900 mm

Working area(m)

2.7-3.0 m

Sweeper rotation speed(r/min)

80 r/min

Cleaning capacity

40000m2/h

Sweeper angle
Adjustment

Forerake 4°-6°and extroversion 2°-4°

Remarks

1, Rear LED pilot lamp
2, Self unloading box body
3, Rear vacuum cleaner
4, The tank color is optional




Working Video
