| Brand Name: | FAW |
| Model Number: | CLW |
| MOQ: | 1 |
| Price: | 15000-35000 per unit |
| Payment Terms: | 50% Deposit,Balance should be paid before ship out |
| Supply Ability: | 10unit per month |
FAW (First Automobile Works) is one of China's largest truck manufacturers and offers a range of vehicles suitable for transporting heavy construction equipment like excavators. These vehicles typically fall into two main categories: Rigid Flatbed Trucks and Low-Bed Semi-Trailers.
FAW (First Automobile Works) is a major Chinese automotive manufacturer that produces a wide range of vehicles, including heavy-duty flatbed and low-bed trucks designed for transporting excavators and other heavy machinery.
FAW produces various models of flatbed trucks and low-bed semi-trailers tailored for excavator and heavy machinery transport. These trucks are widely used in construction, mining, and other industries for moving equipment like:
| Feature | Typical Specifications |
|---|---|
| Common Models | FAW 2, 3, or 4-Axle Low-Bed Semi-Trailers |
| Carrying Capacity | Heavy-duty models typically range from 40 tons up to 100 tons (and sometimes higher). This is necessary for medium to large excavators and other heavy machinery (rollers, loaders, graders). |
| Axles | 2, 3, or 4 axles (often 13T or 16T capacity) from brands like FUWA, BPW, or ZHENGYANG. |
| Platform Design | Low-bed design, which features a drop in the deck height. This ensures a low center of gravity for maximum stability when hauling tall machinery like excavators. |
| Loading Ramp | Equipped with heavy-duty spring ramps or hydraulic ramps for the excavator to drive onto the main deck. |
| Chassis/Tractor | Often paired with a powerful FAW Jiefang series prime mover ( J6P or JH6) with a high horsepower engine ( 380 HP to over 500 HP). |
| Material | Main beam construction uses high-strength steel ( Q345B) for durability and load-bearing capacity. |
| Feature | Typical Specifications |
| Drive Type | Common configurations are 6x4 or 8x4 (for heavier loads). 4x2 is used for light-duty transport ( 8-10 tons). |
| Gross Vehicle Weight (GVW) | Upwards of 25,000 kg, depending on the axle configuration. |
| Load Capacity | Rigid 8x4 models can often handle excavator loads of 30 to 35 tons (payload, excluding the truck's weight). |
| Deck | A reinforced flatbed platform, often made of checkered plate steel for better traction. |
| Loading Ramp | Includes a fixed or foldable rear ramp/ladder (often hydraulically or manually operated) for machinery to drive on. |
| Engine | Equipped with heavy-duty diesel engines, like those from FAW's Xichai or Weichai engines, often in the 300 HP to 400 HP range. |
More Excavator carrier lorry :
| items | Descriptions | Specifications and Types |
|---|---|---|
| General | Truck Name | FAW Flat Truck |
| Drive Type | 4*2 | |
| Gross Vehicle Weight(kg) | 25000 | |
| Curb Weight (kg) | 12500 | |
| Overall Dimensions L*W*H(mm) | 9000*2500*2820 | |
| Engine | Engine Brand | WP10.310E40 |
| Fuel Type | Diesel | |
| Power | CA6DLD-22E5 | |
| Emission Standard | Euro 3/4 | |
| Displacement(ml) | 9726 | |
| Engine Type | 4 cylinders in line, turbo-charged diesel engine,inter-cooling,high pressure common rail | |
| Chassis | Chassis Brand | CA1180P1K2L5E5A80-1 |
| Tire No. | 6+1 | |
| Tire Specification | 295/80R22.5 | |
| Wheelbase (mm) | 4500 | |
| Axle No. | 3 | |
| Gear Box | 5 speed forward with 1 reverse, manual | |
| Brake | Air brake | |
| Steering Wheel | Left hand drive with power-assisted | |
| Stage | Stage Area(m2) | 36 to 40, three sides open |
| Operation Type | Hydraulic Operation |
Establishment: Founded in September 2004 (its predecessor was Chengli Special Automobile Co., Ltd.).
Headquarters: Suizhou City, Hubei Province, China.
Scale: The broader CLW Group has substantial assets, covering a large area with multiple production bases, including one in Wuhan and Xiangyang. It employs thousands of staff, including many technicians and skilled workers.
Capacity: The company boasts a high annual production capacity, often cited as around 100,000 special vehicles.
Reputation: Recognized as a "China Famous Brand," a "National High-tech Enterprise," and frequently ranks among the Top 500 Chinese Private Enterprises and top manufacturers in Hubei Province.
Established in Sep. 2004,Chengli Special Automobile Co., Ltd is an important branch of CLW group with registered capital 100,000,000 RMB(14
millions US Dollars) and total capital 6,000,000,000(840 millions US Dollars).
Chengli Special Automobile Co., Ltd. (CLW Group) has a strong focus on the international market, leveraging its position as one of China's largest special vehicle manufacturers.
The company's products are exported to a wide and growing number of countries and regions, often cited as more than 50 countries or regions worldwide.
Trucks from Chengli Special Automobile Co., Ltd have been sold to more than 29 provinces in China and more than 80 overseas countries and regions in
Asia, Africa, South America, middle east and so on, such as Russia, Mongolia, Philippines, Vietnam, Cambodia, Myanmar, Laos, Kazakhstan, Uzbekistan,
Kyrghzstan, Tanzania, Zambia, Nigeria, Australia, Chile, Bolivia, Ethiopia, Sudan, Malaysia, Congo, El Salvador, Iraq, New Zealand, Chile, Bolivia, Argentina and also truck body for client drawing
Address
Chengli Automobile Industry Park,Suizhou City,Hubei Province,China
Tel
86--18995979503
