| Brand Name: | HOWO |
| Model Number: | CLW |
| MOQ: | 1 |
| Price: | 15000-35000 per unit |
| Payment Terms: | 50% Deposit,Balance should be paid before ship out |
| Supply Ability: | 10unit per month |
Heavy Machinery Transport: Moving small to medium construction equipment (mini-excavators, bobcats, rollers, forklifts) between job sites.
Vehicle Recovery/Wrecking: Using the winch and flatbed to load and transport disabled or broken-down vehicles.
Logistics and Freight: Using the crane to efficiently self-load/unload heavy cargo, pallets, or building materials on delivery routes.
Construction/Field Service: Serving as a mobile utility and service truck that can lift and place materials or equipment in hard-to-reach areas.
| Feature | Typical Specification Range |
| Drive Type | 4x2 |
| Tyre Configuration | 6 Tyres (Single front axle, dual rear axle, plus 1 spare |
| Gross Vehicle Weight (GVW | 11,495 kg - 12,000 kg 11.5 to 12 metric tons |
| Curb Weight (Tare Weight | 6,000 kg - 10,000 kg(Varies significantly with crane and superstructure |
| Actual Loading Capacity (Payload | 5 tons - 6 tons (5,000 kg - 6,000 kg |
| Overall Dimensions (L x W x H | 7,200 mm - 9,150 mm * 2,250 mm - 2,500 mm * up to 3,700 mm |
| Wheelbase | 3,300 mm - 4,700 mm |
| Flatbed Cargo Length | 5,300 mm - 6,600 mm |
| Feature | Typical Specification Range |
| Engine Brand/Model | Cummins (B140-33, ISB180 50 or Yuchai (YC4E160-33 |
| Engine Power | 140 HP - 190 HP(103 kW to 140 kW |
| Emission Standard | Euro III, Euro IV, or higher |
| Gearbox | Manual, 6-speed or 8-speed (Fast 6-speed or WLY6TS55C |
| Front Axle Capacity | 3.2 tons - 3.6 tons |
| Rear Axle Capacity | 8.0 tons - 9.0 tons |
| Tyre Specification | 8.25R20 or 9.00R20 |
| Feature | Typical Specification Range |
| Crane Lifting Capacity | 6.3 tons - 8 tons (Commonly XCMG or other Chinese brands |
| Crane Type | Straight Telescopic Boom (Stiff Boom or Knuckle Boom (Folding Arm |
| Maximum Lifting Height | 10 m - 14 m |
| Winch Rating | 4 tons - 6 tons Hydraulic Winch |
| Ramp Angle | 8degree - 10degree (For flatbed tilt/ramp |
| Outriggers | Hydraulic (2 front stabilizers are standard; rear outriggers are often optional |
| Main Specifications | ||
| Dimensions | Overall dimensions | 7650mmx2250mmx2390mm |
| Cargo box length | 5300mm | |
| Wheelbase | 4200mm | |
Weight |
Actual loading weight | 6000kg |
| The total mass | 12000kg | |
Engine |
Model | Weichai |
| Power | 226hp | |
| Exhaust standard | Euro III | |
Gearbox |
Model | Fast 6-speed |
| Type | Manual | |
Axle |
Front axle | 3.6T |
| Rear axle | 9T | |
