ISUZU 7cbm Diesel Road Street Sweeper Sweep Sweeping Vacuum Cleaner Cleaning Truck

The ISUZU 7 cbm (cubic meter) Diesel Road Street Sweeper is a specialized sanitation vehicle manufactured by companies like Chengli Special Automobile Co., Ltd., built on a reliable ISUZU chassis.

road sweeper truck (also called street cleaning truck , truck mounted sweeper , Road cleaning truck , street sweeping truck ) Is used for all cleaning , brushing and vacuum collecting of surface dusts , leaves , mud , soil , sand , stone chips , gravels and other small particles on the ground of city / municipal roads and areas .

It is suitable for dry type cleaning job as well as dust suppression with water spray in the road side and narrow lanes . It is composed of water tank , dustbin , sprayers , sweeping brooms , auxiliary engine , air blower , etc . It is widely used in the municipal sanitation filed because of convenient operation and high efficiency .

1. Purpose: Sweeper truck can be widely used in main city road,airport road,residential area road, park,terminal, square, cement factory, power plant and etc.

2. Main parts: Stainless steel dust tank and water tank, Germany hydraulic oil pump and magnetic valve, French Schneider eletronic control switch, auxiliary engine, suction panel, sprinkler system, sweeping brush.

3. Feature: On the basis of one-key control technology, the manual throttle control system of the auxiliary engine is added, which can independently adjust the throttle size according to the road condition, effectively enhancing the cleaning effect and reducing fuel consumption.

• The garbage bin is made of stainless steel with a filter plate inside, which can effectively prevent light objects such as leaves from blocking the air outlet and dust from being discharged.
• Anti-corrosion, anti-rust and anti-virus treatment inside the water tank.
• The cleaning structure of "Center 4 brush + rear suction cup", the front sweeping disk has automatic obstacle avoidance function, and the left and right sweeping brushes can be controlled separately.
• According to the user's needs, it can be equipped with pre-shooting, post-sprinkling, spraying, self-cleaning reel, operation monitoring system, auxiliary suction device and snow shovel.

Sweeping and Collection: It uses a combination of rotating side brushes and a powerful central vacuum suction system to efficiently pick up dust, leaves, gravel, mud, and other small debris from urban streets, highways, airports, and industrial areas.

Dust Suppression: Water sprinklers are equipped on the brooms and suction nozzle to spray a fine mist, which effectively controls and minimizes airborne dust during the sweeping process.

Operation: The independent auxiliary engine allows the sweeping and vacuum system to operate at full power even when the main vehicle is moving slowly or idling, ensuring consistent cleaning efficiency.

The Vacuum Sweeper Truck is mainly used for road dust cleaning and suction. It is widely used in seaports, coal mining places, urban roads, highways, airports, docks, Bridges, squares, residential areas etc to make the places.

A Road Suction Truck can largely save labor cost and working time. To use the Sweeper Truck one hour can match a person sweeping the road all day!

Hydraulic System: Uses high-quality components (e.g., imported motors or solenoid valves) to control the movement and rotation of the sweeping brushes, hopper lifting, and rear door opening.

Electric Control: All sweeping and cleaning functions are typically controlled by a centralized electronic control panel integrated inside the cabin for easy, one-person operation.

Safety Features (Optional/Standard):

• Left/Right sweeping brushes can be controlled separately.
• Front sweeping disc often has an automatic obstacle avoidance function.
• Warning lights, music alarm, and optional backup alarm/camera system.
• Hydraulic dump angle of the dustbin is typically ≥45 ∘ for complete and fast unloading.

1. With auxiliary engine. It is with JMC 64KW vice engine and supply enough power for the suction devices. The vice engine is connected to the fan adopts automatic centrifugal clutch, can guarantee the vice engine no-load start.

2. Vacuum device and suction nozzle arrangement adopts "wide of suction nozzle by the main suction + left and right side suction nozzle structure arrangement. The suction cup device has the function of avoiding and resetting automatically when encountering obstacles.This function can effectively solve the problem of easily damaged dust collector. Full floating suction nozzle, with the characteristics of large vacuum width, high vacuum efficiency, and conducive to the adjustment and maintenance of suction nozzle.

3. The liner of dustbin adopts double structure, the inner layer is all stainless steel;The high efficiency filtration of 4 sets of polymer filter cylinders can effectively reduce the secondary pollution caused by dust.

4. The front part of the truck is equipped with an automatic emergency system of hand pump.The tail is equipped with an optional water spray dust removal device;Open and close the garbage box door and garbage dump can be operated in the driving room, which is safe, convenient and reliable.

5. The filter cylinder of the vacuum truck can effectively separate the dust absorbed by the vacuum truck so as to avoid secondary dust pollution. There are two cleaning methods for the filter cylinder of the vacuum truck, one is equipped with automatic pulsed dust cleaning, and the other is disassembled and cleaning. Both are easy to operate.

Chengli Special Automobile Co., Ltd. is a massive and highly influential manufacturer of special-purpose vehicles in China, and the core enterprise of the Chengli Automobile Group (CLW Group)

Established in Sep. 2004,Chengli Special Automobile Co., Ltd is an important branch of CLW group with registered capital 100,000,000 RMB(14 millions US Dollars) and total capital 6,000,000,000(840 millions US Dollars).

Export Markets: Chengli has successfully exported its special-purpose vehicles to over 50 to 80 countries and regions worldwide.

Annual Volume: The company reports exporting tens of thousands of trucks annually, with annual export earnings reported to be in the tens of millions of US dollars.

Export Base Status: The company has been officially identified by the Hubei Provincial Government as the province's Auto & Parts Export Base and Special Trucks Modification Emergency Security Center, highlighting its importance in Chinese vehicle export.

Trucks from Chengli Special Automobile Co., Ltd have been sold to more than 29 provinces in China and more than 80 overseas countries and regions in Asia, Africa, South America, middle east and so on, such as Russia, Mongolia, Philippines, Vietnam, Cambodia, Myanmar, Laos, Kazakhstan, Uzbekistan, Kyrghzstan, Tanzania, Zambia, Nigeria, Australia, Chile, Bolivia, Ethiopia, Sudan, Malaysia, Congo, El Salvador, Iraq, New Zealand, Chile, Bolivia, Argentina and also truck body for client drawing
